HD108 NS108 Addressable led strip HD108 original IC Developer

The maximum serial data input frequency 40MHZ, refresh rate of up to 27KHz, cascade up to 1024 points. RGB three-color output control, 64Bit (65536 level) color settings. NS108, the best digital LED in market.
Description Package Information Inquiry

Newstar led developed NS108 IC is a two-wire transmission three-channel (RGB) drive control circuit and light-emitting circuit in one of the intelligent external control LED light source. Built-in constant current circuit and RC oscillator; internal integrated current gain control module, CMOS process, low voltage, low power consumption; when REXT is floating, the three-channel constant current driver default output of 18mA, the product is equipped with signal decoding module, Can also be REXT external resistor to adjust the required current, each output channel can output 16 (65536 level) gray adjustable linear current; using two-wire output, DATA data and synchronous CLK signal, so that the series chip The output action synchronization; refresh rate up to 27KHz, showing more delicate and smooth, the default power does not light.


HD108 5050 Addressable LED Strip Feartures:

1. HD108 with transmission rate 40MHz

2. PWM refresh rate>27KHz (APA102 with PWM frequency 20KHZ, APA107 with 9KHz, SK9822 with 4.7KHZ,)

3. HD108 LED with a much lower voltage drop than APA102/SK9822 LED, but higher brightness

4. HD108 LED is with the same protocol as APA102

5. HD108 with a larger lighting beam angle

6. Copper bracket and gold wire to keep a good heat dissipation

7. Choose positive output or negative RGB three-color LED output 66535 grayscale(16bit) and 32(5bit) level brightness adjustment

8. With self-detection signal build in support for continuous oscillation PWM output, can be maintained static screen
